Product Overview
The Ericsson Cradlepoint S700 is the semi-ruggedized LTE router for equipment and vehicles that need more than a cabinet box: an aluminum housing, two gigabit ports, dual-band Wi-Fi 6, active GNSS, ignition sensing on 9 to 33 VDC, and a 480 Mbps stateful firewall. It carries MIL-STD-810H shock and vibration, SAE J1455 vehicle, and EN 61373 rail ratings.
That combination makes it the go-to for utility trucks, transit and rail equipment, mobile assets, and industrial sites where a plastic-housed IoT router would not last. It is FirstNet Trusted, so public-safety fleets can use it for secondary vehicles and equipment that do not justify an R1900.
What the SKU includes: every option on this page bundles the router with its Ericsson NetCloud plan for the term you choose (IoT Essentials, or IoT Essentials + Advanced, for 1, 3, or 5 years). NetCloud is required to configure and manage Cradlepoint hardware, and the hardware warranty runs for as long as the plan is active.
Specifications
| Cellular | LTE Cat 4 (3GPP Rel. 11) with DC-HSPA+; 2x2 MIMO; peak 150 Mbps DL / 50 Mbps UL; 2x SMA antenna connectors |
|---|---|
| SIM | Dual 4FF SIM slots; SIM-based automatic carrier selection |
| Ethernet | 2x GbE RJ45, LAN/WAN switchable |
| Wi-Fi | Dual-band concurrent 2x2 802.11ax (Wi-Fi 6): 574 Mbps + 1.2 Gbps; 2x RP-SMA connectors; WPA3 |
| Expansion / GNSS | 1x USB 2.0; 1x SMA GNSS connector; active GNSS (GPS, GLONASS, BeiDou, Galileo) |
| Performance | Stateful firewall 480 Mbps; IPS/app-aware 480 Mbps; IPsec VPN 50 Mbps; 10 VPN tunnels; 100,000 sessions; typical 20 clients |
| Power | 9 to 33 VDC with ignition sensing (auto on, delayed off); ISO 7637-2 protection; 9 W idle, 14.5 W heavy |
| Environmental | -20 to 60 C operating; IP30; MIL-STD-810H shock and vibration; SAE J1455 vehicle; EN 61373 rail; aluminum housing |
| Size / weight | 123 x 118 x 34 mm (4.8 x 4.6 x 1.3 in); 516 g (18.2 oz) |
| Certifications | FirstNet Trusted, T-Mobile Connecting Heroes, Verizon Frontline; AT&T, T-Mobile, Verizon; PTCRB; FCC/IC; UL/cUL |
| Management | Ericsson NetCloud Manager, IoT plan (included in each SKU); RCN's U.S.-based 24/7 NOC is available as a managed service (quoted separately) |
Ericsson Cradlepoint S700 series datasheet
Right for you if
- The router rides in a truck, bus, rail car, or trailer and needs ignition sensing
- You want Wi-Fi 6 for tablets, cameras, or a crew network on the vehicle
- Two wired ports are needed for a camera and an MDT or controller
- FirstNet Trusted hardware is required but an R1900 is more than the vehicle needs
S700 vs. S750 vs. R980
Choose the S700 for LTE with Wi-Fi in a rugged housing. The S750 is the same router without Wi-Fi. When the vehicle needs 5G and 940 Mbps of firewall, move to the R980, or to the R1900 for four gigabit ports. For a cabinet or kiosk that never moves, the S400 costs less.
Common deployments
Utility and public-works fleets, transit and rail rolling stock, mobile equipment and trailers, industrial IoT, and secondary public-safety vehicles.
What RCN adds
- Pre-provisioning: RCN can stage the unit in your NetCloud account so it ships ready to power on
- Installation nationwide through RCN's in-house install team (quoted separately)
- U.S.-based 24/7 NOC monitoring and support as a managed service (quoted separately)
- Purchase on GSA Schedule, NASPO ValuePoint, Sourcewell, OMNIA Partners, or Equalis Group, or on a PO for approved accounts
FAQ
Is it FirstNet approved?
Yes. The S700-C4D is FirstNet Trusted and also certified for T-Mobile Connecting Heroes and Verizon Frontline. RCN can provision it on a FirstNet SIM before it ships.
Is the NetCloud subscription included?
Yes. Each SKU pairs the S700 with the NetCloud plan and term shown in the option name. Renewals are quoted before the term ends so the device never drops off management.
Does it come with antennas and a power supply?
Yes. Cradlepoint's ordering guide lists the S700 part numbers sold here (TB03, TB05, TBA3, and TBA5-0700C4D-NN) as including an AC power supply and antennas. The antennas are two external cellular paddle antennas that attach to the router's SMA connectors.
Can we purchase on a purchase order or government contract?
Yes. RCN sells through GSA Schedule and cooperative contracts including NASPO ValuePoint, Sourcewell, OMNIA Partners, and Equalis Group, and can invoice approved accounts on a PO.
What if it turns out to be the wrong model?
Talk to RCN before you order. We deploy this hardware every week and will tell you if a smaller or larger unit fits better; the comparison section above is a good start.
Antennas that fit the S700
The S700 has two SMA cellular connectors, two RP-SMA Wi-Fi connectors, and one SMA GNSS connector. For a vehicle roof, a cabinet, or a spot with weak signal, these Panorama antennas match those ports:
- Panorama SH-IN2617 Sharkee kit: 2x2 MIMO cellular, 2x2 Wi-Fi, and GPS in a roof-mounted shark fin. Covers 617–960 and 1710–6000 MHz, with 5 m cables. Choose the SH-IN2617 option to include Wi-Fi.
- Panorama LG-IN2457 5-in-1 dome kit: 2x2 MIMO cellular, two Wi-Fi elements, and GPS in a roof-mounted dome. Covers 617–960, 1710–3800, and 4900–6000 MHz, with 5 m cables.
- Panorama BATGM-7-60-24-58 covert antenna: 2x2 MIMO cellular, 2x2 Wi-Fi, and GPS in a covert unit that mounts inside the vehicle on the dash or glass, with 3 m cables. Choose the BATGM-7-60-24-58 option to include Wi-Fi.
- Panorama LGAM-7-27-24-58 antenna: 2x2 MIMO cellular, two Wi-Fi elements, and GPS in a single-hole panel-mount housing rated IP66, for a vehicle roof or cabinet. Covers 698–960 and 1710–3800 MHz, with 3 m cables.
Compare more options in the antenna finder, or request a quote and we will confirm the right antenna and cable length for your install.
